Touchdisplay 10.1" PoE+ HD Flex OS 20-3008-1085
20-3008-1085
The door sign supports videos, images, HTML5 web content and audio files in multiple display areas or as playlists. Content can be managed via the network using BrightAuthor or easescreen. GPIO and RS-232 allow individual sequences to be triggered, while multiple devices can be synchronized. Additional features include online reports, text tickers, RSS feeds, statistics, world time and date display. Depending on the hardware, BrightSign OS, Windows, Android or Linux can be used.
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Display:
- 10.1" LCD
- 10-point capacitive multitouch
- 1280 x 800
- 450 nits
- 2 x 1.5 W speakers
- VESA mounting: 100 x 100 mm (M4)
Input:
- 1 x MicroSDHX card slot (up to 2 TB)
Outputs:
- 1 x 3.5 mm audio jack (analog)
Control:
- Network (Gbit / PoE+)
- Optional Wi-Fi
- USB
- RS232
- 4 x GPIO
- IR (In / Out)
Supported Formats:
- Video: H.265, H.264 (MPEG-4, Part 10), MPEG-2 and MPEG-1
- Video Containers: .ts, .mpg, .vob, .mov, .mp4, .m2ts, .wmv
- Image: BMP, JPEG and PNG
- Audio: MP2, MP3, AAC, OGG, WAV (AC3 pass-through)
- HTML5: Mainstream
