Mediaplayer HDMI2.0 UHD/4K, HDMI2.0 IN, LAN, 2 USB 3.0, RS232, 8 GPIO 4K1142

Hersteller

4K1142

Capable of playing Videos (up to: 2 x 1080p or 4 x 720p/1080i), Images and Audio files in multiple zones or as looping playlists. Content may be added or changed over the network using BrightAuthor or Easescreen (coming soon) software. Event sequences can be triggered by GPIO, Ethernet (UDP), RS232, USB and USB Touch Screens. Synchronization of multiple Players over the network. Additional features are: Playlist scheduling, Online Reports, Text ticker, RSS Feed and Twitter Feeds. Event Logging and displaying of World Time including Date are supported as well. Power your 4K player over Ethernet with Power over Ethernet + (Type 2) which can support up to 25 watts of power

€ 0,00 Excl. VAT .

Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschließend eine kostenlose Beratung an!

Description


Technical Specification

Input:
1 x SDXC slot (up to 2TB)
1 x HDMI2.0 female
Outputs:
1 x HDMI2.0 female
1 x Toslink optical Audio female
1 x 3,5mm mini Jack Audio female
1 x 3,5mm mini Jack IR female
Control options:
LAN, CEC, 8 GPIO (bi-directional), RS232, IR, 3 x USB (2 x USB3.0)
Resolutions supported:
HDMI: 4K native (4096x2160/ 3840x2160), 1080p, 1080i, 720p, 576p, 480p, 800x600, 960x960, 1024x768, 1280x768, 1280x800, 1280x960, 1280x1024, 1360x768, 1440x900, 1440x1050, 1600x1200, 1680x1050, 1920x1200
Video: PAL/ NTSC/ SECAM
Formats supported:
Video: MPEG-1, MPEG-2 , H.264, WMV, MPEG2 TS, PS, AVCHD/BDAV, ASF, MP4, 3D (MVC, side-by-side, top-over-bottom, frame-packing)
Picture: HTML5, BMP, JPEG and PNG
Audio: MP2, MP3, AAC, WAV (AC3 pass trough)

Producer
BrightSign LLC
Product
4K1142
Gehäuse
Metall
Weight (kg)
1,95
Color
Lila
Power supply type
Extern
Stromversorgung
12V, 5A oder PoE+ Type2
Operating
0° C - + 40° C
Abmessungen BxHxT mm
168 x 69 x 149 mm
Artikel Nr.
5857
