Mediaplayer 3840x2160@60Hz, LAN, 8 GPIO XD233

Hersteller

XD233

Full screen or multi screen layouts, looping playlists, webside HTML5 (Advanced), Update content via LAN, synchronisation of several media players over LAN, online reports, text ticker or RSS-feed, worldclock with date.

€ 0,00 Excl. VAT .

Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschließend eine kostenlose Beratung an!

Description


Technical Specification

Input:
1 x Micro SDXC slot (up to 2TB)
Outputs:
1 x HDMI female
1 x 3,5mm mini Jack Audio female (analog & digital)
Control options:
LAN (Gbit), WLAN optional, CEC, 8 GPIO, IR (In/ Out)
Resolutions supported: (UHD)
3840x2160x24/ 25/ 30/ 50/ 60Hz
Resolutions supported: (Upscaling)
3840x2160x24/ 25/ 29.97/ 30Hz
Resolutions supported: (Full HD)
1920x1080@24/ 25/ 29.92 /30 /50 /59.94 /60Hz,
1920x1080x50/ 59.94 /60i, 1600x1200x60Hz, 1440x1050x60/ 75Hz, 1440x900x60/ 75Hz, 1360x768x60Hz, 1280x1024x60/ 75Hz, 1280x960x60Hz, 1280x800x60 /75Hz, 1280x768x60Hz,
1280x720x50/ 59.94/ 60Hz, 1024x768x60Hz, 800x600x60/ 75Hz, 720x576x50Hz/50i, 720x480x59.94/ 60Hz/60i, 640x480x60Hz
Formats supported:
Video: H.265 (4K) .ts, .mov, .mp4, .mkv & H.264 (1920x1080)(MPEG-4, Part 10), MPEG-2 und MPEG-1
Video codec: .ts, .mpg, .vob, .mov, .mp4, .m2ts, .wmv
Bild: BMP, JPEG and PNG
Audio: MP2, MP3, AAC, WAV (AC3 pass trough)
HTML5: Advanced

Producer
BrightSign LLC
Product
XD233
Gehäuse
Metall
Weight (kg)
1,30
Color
Lila
Power supply type
Extern
Stromversorgung
12V, 3A (36 Watt)
Operating
0° C - + 50° C
Abmessungen BxHxT mm
179,9 x 21,9 x 204,2 mm
Artikel Nr.
6669
