Converter 3G-SDI to HDMI SC1112
SC1112
Converts a HDMI Signal (max. 1080p60Hz) into a SDI Signal. The output signal is simultaneously on 2 BNC available.
€ 119,00 Excl. VAT .
Legen Sie dieses produkte in den Beraterkorb und fordern Sie anschlieÃend eine kostenlose Beratung an!
Description
Technical Specification
Input: 1 x HDMI fe.
1 x USB-Mini (power)
Output: 2 x BNC fe
HDMI Input Formats:
1080p 50/59.94/60
1080p23.973/23.98/24/25/29.97/30
1080i50/59.94/60
720p50/59.94/60
PAL 625i 50, NTSC 525i 59.94
Colorspace: YUV 4:2:2
SDI Output Formats: like HDMI
Producer
AVMatrix
Product
SC1112
Gehäuse
Metall
Weight (kg)
0,50
Color
Gelb-Grün
Power supply type
Extern
Stromversorgung
3,3-5 V / 1,5 W
Operating
-20° - 60° C
Abmessungen BxHxT mm
90 x 94 x 23
Artikel Nr.
7546
